Vacuum Lifter – uniLifter

The uniLifter features a modern and innovative design for safe handling of non-porous items, such as metal, plastic sheets, glass or windows. This unique vacuum lifting device is available in a number of options that lift, rotate and tilt materials.

A multipurpose lifter that is suited for a number of industries, the uniLifter Vacuum Lifter is equipped with advanced safety features like load monitoring, two hand release function and special handling controls to assist in increasing productivity. The unit is constructed with an ergonomic control console that allows one-hand operation and easy vacuum lifting.

The uniLifter has quick-release functionality for fast operation. With an integrated chain hoist, this product improves handling capabilities and makes light work of heavy loads.

Product Variation

Clear

Additional Information

Stable and lightweight vacuum lifting devices!

The uniLifter safely handles the workpiece and ensures operators are protected. Featuring blow-off technology, it can quickly release panes for efficient operation. These vacuum devices provide infinite lifting opportunities. With overload control and a variety of suction beams, they can overcome a variety of applications.

UGL 1 uniLifter Vacuum Lifter – lifting only

The UGL 1 uniLifter is perfect for lifting either vertically or horizontally. It is suitable for materials up to 3200 x 2500 mm. The device can efficiently handle loads with a capacity of either 250 kg or 500 kg.

Lifting Height – 2000 mm
Operating Voltage – 240 V / 50 Hz
Load Capacity – 250 kg or 500 kg
Lifting Speed – 0-10 m/min variable speed
Compressed Air Required – 6 bar dry, filtered

UGL 2S uniLifter Vacuum Lifter – lifting and rotating only

This model features a unique 200° rotation function with the workpiece in the vertical position. The UGL 2S can easily lift and rotate up to 3200 x 2500 mm in size and is ideal for glazing work. Featuring a very compact body, an operator can maintain a vision of the glass pane at all times. The unit is ideal for vertical transport of loads up to a maximum capacity of either 250 kg or 500 kg.

Rotation Function – 200°
Lifting Height – 2000 mm
Operating Voltage – 240 V / 50 Hz
Load Capacity – 200 kg or 250 kg
Lifting Speed – 0-10 m/min variable speed
Compressed Air Required – 6 bar dry, filtered

UGL 3 uniLifter Vacuum Lifter – lifting and tilting only

The UGL 3 device features a compact body to allow an easy view of the glass. It’s suitable for a variety of lifting activities and has a pneumatic tilting function that tilts horizontally through 90° to vertical. The unit handles up to 3200 x 2500 mm in size and capacities up to 250 kg or 500 kg.

Tilting Function – 90°
Lifting Height – 2000 mm
Operating Voltage – 240 V / 50 Hz
Load Capacity – 250 kg or 500 kg
Lifting Speed – 0-10 m/min variable speed
Compressed Air Required – 6 bar dry, filtered

UGL 4 uniLifter Vacuum Lifter – lifting, rotating and tilting

The UGL 4 uniLifter is a versatile solution as it features the ability to rotate glass 200° and tilt 90°. It can efficiently handle materials with a maximum size of 3200 x 2500 mm and is suitable for capacities up to 250 kg or 500 kg.

Tilting Function – 90°
Rotating Function – 200°
Lifting Height – 2000 mm
Operating Voltage – 240 V / 50 Hz
Load Capacity – 300 kg or 500 kg
Lifting Speed – 0-10 m/min variable speed
Compressed Air Required – 6 bar dry, filtered

UGL 2N uniLifter Vacuum Lifter – lifting and rotating only

With a narrow main body, the UGL 2N uniLifter is best suited for applications where glass is picked up from vertical racks. It features an electric motor for 100° rotation and can handle a maximum capacity of up to 250 kg

Rotating Function – 100°
Operating Voltage – 240 V / 50 Hz
Load Capacity – 250 kg
Lifting Speed – 0-10 m/min variable speed
Compressed Air Required – 6 bar dry, filtered

Check out our Glass miniLifter in the uniLifter series!

This device can quickly handle materials for fast manipulation and effortless use. This Single Hand Rotator provides fast and variable lifting speeds and rotating while vertical functions. The controls are simple to use and intuitive, while both hand operation allows for a quick and safe release.

View the entire range!

uniLifter offers integrated control systems that simplify lifting processes. View our entire range to see how performance can be increased in your workplace.

Product Variations

Description	Product Code
UGL 1 uniLifter 250 kg Handling flat glass up to 3.2 x 2.5 m Vacuum ejector with “push off” release of workpiece Includes safety release system by load detection Four 270mm suction cups adjustable on H beam	99205	Add to Quote Request
Option: capacity 500 kg (add to 99205) Suction cups BA 350 and safety system with load management	99621	Add to Quote Request
UGL 2S uniLifter 200 kg Vertical handling of flat glass up to 3.2 x 2.5 m Electric rotation mechanism 200 ° Vacuum ejector with “push off” release of workpiece Comfort controls fixed on the main body Two 270mm suction cups fixed on the beam	99206	Add to Quote Request
Special body for the use of special beams and incl. manual adjustment of center of gravity [Add this to 99206]	99622	Add to Quote Request
Option: capacity 250 kg (add to 99206) 2 suction cups BA 350 fixed on the beam	99504	Add to Quote Request
UGL 2 uniLifter 250 kg Vertical handling of flat glass up to 3.2 x 2.5 m Electric rotation mechanism 200 ° Vacuum ejector with “push off” release of workpiece Includes safety release system by load detection Four 270mm suction cups adjustable on H beam	99207	Add to Quote Request
UGL 3 uniLifter 250 kg Handling and tilting of flat glass up to 3.2 x 2.5 m Pneumatic tilting 90 ° Vacuum ejector with “push off” release of workpiece Includes safety release system by load cell Four 270mm suction cups adjustable on H beam	99208	Add to Quote Request
UGL 4 uniLifter 250 kg Handling tilting and roating flat glass up to 3.2 x 2.5 m Electric rotation mechanism 200 ° Pneumatic tilting 90 ° Vacuum ejector with “push off” release of workpiece Includes safety release system by load detection Four 270mm suction cups adjustable on H beam	99209	Add to Quote Request
Option: upgrade lifting capacity to 500kg (add to 99207 99208 99209) Suction cups BA 350	99623	Add to Quote Request
Operating handle tiltable (add to 99206) The operating handle is mounted on a tiltable boom. Locking by a clamping lever.	99401	Add to Quote Request
Adjustable operating handle: Optimal adjustment by locking at 3 points of articulation	99402	Add to Quote Request
Length adjustable operating handle: This handle is additionally to the swiveling boom even 350 mm adjustable in length	99403	Add to Quote Request
Cross beam 250 kg lockable with 2 suction cups BA 350 Optionally available with 2 suction cups BA 270 The suction cups can be locked by means of spring latches in 3 positions (For model uniLifter B2s only in combination with special body 99622)	99505	Add to Quote Request
Cross beam for window 250 kg until max. 400 kg Suitable for transporting windows and doors with glazing bars with adjustable distance between the beams. (For model uniLifter B2s only in combination with special body 99622)	99506	Add to Quote Request
Telescopic beam 200 kg Suitable for transporting windows and doors on the outer frame The offset slide is equipped with a parallel guide wherein when adjusting one side the other side is automatically adjusted with (For model uniLifter B2s only in combination with special body 99622)	99507	Add to Quote Request
X-Traverse adjustable 250 kg with 4 suction cups BA 270 All suction pads are designed to be adjustable 2 beams incl. suction pads are fully removable (as shown colored blue) (For model uniLifter B2s only in combination with special body 99622 not available for models of the safetyLifter series)	99508	Add to Quote Request
Y-Slip beam 250 kg 2 pcs. with 2 suction cups BA 270 for the stabilization of long thin glass. (not available for models of the safetyLifterseries as well as for model uniLifter B2s)	99509	Add to Quote Request
UGL 2N uniLifter 250 kg Handling of single glass from rack Compact narrow body for picking in tight spaces Electric rotation mechanism 100 ° Vacuum ejector with “push off” release of workpiece Includes safety release system by load cell	99210	Add to Quote Request
